- 產品詳情
特征：
基于成熟技術的領先市場解決方案
體積小，設計輕巧
提高制動性能
最佳性價比
支持先進的制動解決方案，包括線控電控液壓制動系統(EHB)
符合功能安全標準
| Pressure Range different options are available) | 0.50 bar 0-180 bar 0-250bar 0-300 bar | ||
| Proof Pressure (different options are available | 150 bar 250bar 300 bar | ||
| Burst Pressure [different options are available | 250 bar 300 bar 350 bar 450 bar | ||
| Hermetic | Yes/Nc | ||
| Technology | Micro Strain Gaug | ||
| Mounting (different options are available | Cinch Cnch/O-img Thread | ||
| Housing Material (different options are available | Stainless stee Stainless steel 305SS AISi7 | ||
| Connection Type | Spring 3x USCAR KeyD(Can be customized | ||
| Operating Temperature (different options are available | 40°to 120°C 40°to 125°C 40 to 1302C | ||
| VSupply (different options are available | 5.0V±0.25V 5.0V±0.375V | ||
| Tipical Accuracy (different options are available | ±1.7%FS ±2%FS ±3.2%FS | ||
| Output Type | SENT.Analog | ||
| RoHS Compliant | Yes | ||
| Supporting IS026262 | Yes | ||
| IP protection class different options are available) | IP30 Solid 6Kx Water x9K | ||
| Media (different options are available | Air Oil Fuel | ||
| Appication | Brakes,Suspension,Transmissio | ||
