BOV-H型OCXO恒溫晶振頻率10-40MHz

發布于:2024-01-09 08:36:54

品牌名稱:Bliley

重要參數:

頻率:10 至 40MHz

穩定性:±20ppb、±50ppb、±100ppb

溫度范圍:-20°C至+70°C,-40°C至+85°C

電壓:3.3V 5.0V

封裝:9毫米 x 7毫米

  • 產品詳情

Bliley高性能OXCO產品是頻率控制行業85年的成果?,F(xiàn)代布局拓?fù)涫笲liley能夠?yàn)樗袘?yīng)用程序設計和生成強大的設計。

特性:

表面貼裝設計

具有非常高的溫度穩定性

快速熱身時間

低年齡比率

低相位噪聲

9.7x7.7mm包裝



其他型號:

FamilyTypeFreq RangeStabilityTemp RangePHN, dBc/HzSupplyPackage
BOV-EOCXO10 to 100MHz±20ppb,
±50ppb,
±100ppb
-20°C to +70°C,
-40°C to +85°C
-120 @ 10Hz
-145 @ 100Hz
-150 @ 1kHz
-155 @ 10kHz
-160 @ 100kHz
3.3v
5.0v
12.0v
25mm x 25mm
BOV-GOCXO2 to 100MHz±20ppb,
±50ppb,
±100ppb
-20°C to +70°C,
-40°C to +85°C
-120 @ 10Hz
-140 @ 100Hz
-145 @ 1kHz
-150 @ 10kHz
-155 @ 100kHz
3.3v
5.0v
25mm x 22mm
BOV-LOCXO10 to 100MHz±20ppb,
±50ppb,
±100ppb
-20°C to +70°C,
-40°C to +85°C
-120 @ 10Hz
-140 @ 100Hz
-145 @ 1kHz
-150 @ 10kHz
-155 @ 100kHz
3.3v
5.0v
14-pin DIP
BOV-HOCXO10 to 40MHz±20ppb,
±50ppb,
±100ppb
-20°C to +70°C,
-40°C to +85°C
(20MHz @ 25C)
-70 @ 1Hz
-100 @ 10Hz
-123 @ 100Hz
-143 @ 1kHz
-147 @ 10kHz
-151 @ 100kHz
3.3v
5.0v
9mm x 7mm
BOV-JOCXO5 to 100MHz±20ppb,
±50ppb
-20°C to +70°C,
-40°C to +85°C
-90 @ 1Hz
-120 @ 10Hz
-140 @ 100Hz
-145 @ 1kHz
-150 @ 10kHz
-155 @ 100kHz
3.3v
5.0v
20mm x 20mm
BOV-BOCXO10 to 100MHz±20ppb,
±50ppb,
±100ppb
-20°C to +70°C,
-40°C to +85°C
-120 @ 10Hz
-140 @ 100Hz
-145 @ 1kHz
-150 @ 10kHz
-155 @ 100kHz
5.0v
12.0v
36mm x 27mm
BOV-POCXO10 to 100MHz±20ppb,
±50ppb,
-20°C to +70°C,
-40°C to +85°C
-80 @ 1Hz
-110 @ 10Hz
-140 @ 100Hz
-145 @ 1kHz
-150 @ 10kHz
-155 @ 100kHz
3.3v
5.0v
9mm x 14mm
