SMCJ5629表面貼裝TVS二極管Microsemi
發布時間:2024-12-04 09:03:22 瀏覽:82
Microsemi 的 SMCG5629 至 SMCG5665A 和 SMCJ5629 至 SMCJ5665A 是一系列表面貼裝的瞬態電壓抑制器(TVS),主要用于保護對低鉗位電壓水平敏感的組件。
產品描述
用途:保護對電壓敏感的組件,適用于高電流脈沖,通常由感性開關瞬變產生。
特點:低輪廓表面貼裝J型或鷗翼型端子,有助于減輕應力和降低重量。與其他MELF風格封裝相比,低平輪廓提供了更容易的插入或自動處理優勢。
篩選選項:提供類似于JAN, JANTX, JANTXV, 和 JANS的篩選選項,通過使用MQ, MX, MV 或 MSP作為部件編號前綴,并根據MIL-PRF-19500/507進行高可靠性篩選。
產品特點
工作獨立電壓:5.5V至171V。
金屬鍵合:確保了產品的可靠性。
可靠性數據:符合JESD22-A108, JESD22-A104, JESD22-A113-B, JESD22-A101-B, 和 JESD22-A102標準。
熱效率高:表面貼裝具有J型或鷗翼型端子,用于應力緩解(平面處理表面和更容易放置)。
最大額定值
工作溫度:-55°C至+150°C。
存儲溫度:-55°C至+150°C。
峰值脈沖功率:1500W(10/1000微秒)。
熱阻:20°C/W。
脈沖重復率:0.01%。
穩態最大功率:5.0W(在25°C時)。
鉗位時間:最大50皮秒(理論值)。
正向電壓:在100安培8.3毫秒時最大3.5V。
應用/優勢
高可靠性:適用于低輪廓表面貼裝位置,易于放置和緩解應力。
輕量化:適用于航空或衛星應用。
浪涌保護:符合IEC61000-4-2和-4-4標準,保護ESD和EFT瞬變。
防雷保護:符合IEC61000-4-5標準,適用于Class 1和2,以及在較低電壓和較高浪涌電流等級下的Class 3和4。
保護敏感組件:如ICs, CMOS, Bipolar, BiCMOS, ECL, DTL, T2L等。
型號參數:
ELECTRICAL CHARACTERISTICS @25℃(Test Both Polarities) | ||||||||||||
MICROSEM Part Number Modified -G Bend Lead | MICROSEM Part Number Modified Bend Lead | Breakdown Voltage* (VsR) MIN.MAX | Test Current (aR) | Rated Standoff Voltage (Vwm) | Maximun Standby Current (o at Mwm) | Maximum Peak Reverse Voltage (Ve max.at Ipe) | Maximum Peak Pulse Current pp | |||||
Vdc | Vdc | mAdc | V | μAdc | V | A | ||||||
SMCG5629 SMCG5629A SMCG5630 SMCG5630A | SMCJ5629 SMCJ5629A SMCJ5630 SMCJ5630A | 6.12 6.45 6.75 7.13 | 7.48 7.14 8.25 7.88 | 10 10 10 10 | 5.50 5.80 6.05 6.40 | 1000 1000 500 500 | 10.8 10.5 11.7 11.3 | 39 143 128 132 | ||||
SMCG5631 SMCG5631A SMCG5632 SMCG5632A | SMCJ5631 SMCJ5631A SMCJ5632 SMCJ5632A | 7.38 7.79 8.19 8.65 | 9.02 8.61 10.0 9.55 | 10 10 1 1 | 6.63 7.02 7.37 7.78 | 200 50 50 | 12.5 12.1 13.8 13.4 | 120 124 109 112 | ||||
SMCG5633 SMCG5633A SMCG5634 SMCG5634A | SMCJ5633 SMCJ5633A SMCJ5634 SMCJ5634A | 9.00 9.5 9.9 10.5 | 11.0 10.5 12.1 11.6 | 1 1 1 1 | 8.10 8.55 8.92 9.40 | 10 10 5 5 | 15.0 14.5 16 15.6 | 100 03 93 96 | ||||
SMCG5635 SMCG5635A SMCG5636 SMCG5636A | 3MCJ5635 SMCJ5635A SMCJ5636 SMCJ5636A | 10.8 11.4 11.7 12.4 | 13.2 12.6 14.3 13.7 | 1 1 1 1 | 9.72 10.2 10.5 11.1 | 5 5 5 5 | 17.3 16.7 19.0 18.2 | 87 90 79 82 | ||||
SMCG5637 SMCG5637A SMCG5638 SMCG5638A | SMCJ5637 SMCJ5637A sMCJ5638 SMCJ5638A | 13.5 14.3 14.4 15.2 | 16.5 15.8 17.6 16.8 | 1 1 1 1 | 12. 12.8 12.9 13.6 | 5 5 5 5 | 22.0 21.2 23 22.5 | 68 71 64 67 | ||||
SMCG5639 SMCG5639A SMCG5640 SMCG5640A | SMCJ5639 SMCJ5639A SMCJ5640 SMCJ5640A | 16.2 17.1 18.0 19.0 | 19.8 18.9 22.0 21.0 | 1 1 1 1 | 14.5 15.3 16.2 17.1 | 5 5 5 5 | 26 25 2 29.1 27.7 | 56.5 51.5 54 | ||||
SMCG5641 SMCG5641A SMCG5642 SMCG5642A | SMCJ5641 sMCJ5641A SMCJ5642 SMCJ5642A | 19.8 20.9 21.6 22.8 | 24.2 23.1 26.4 25.2 | 1 1 1 1 | 17.8 18.8 19.4 20.5 | 5 5 5 5 | 31.9 30.6 34.7 33.2 | 47 49 43 45 | ||||
SMCG5643 SMCG5643A SMCG5644 SMCG5644A | SMCJ5643 SMCJ5643A SMCJ5644 SMCJ5644A | 24.3 25.7 27.0 28.5 | 29.7 28.4 33.0 31.5 | 1 1 1 1 | 21.8 23.1 24.3 25.6 | 5 5 5 5 | 39.1 37.5 43.5 41.4 | 385 40 34.5 36 | ||||
SMCG5645 SMCG5645A SMCG5646 SMCG5646A | SMCJ5645 SMCJ5645A SMCJ5646 SMCJ5646A | 29.7 31.4 32.4 34.2 | 36.3 34.7 39.6 37.8 | 1 1 1 1 | 26.8 28.2 29.1 30.8 | 5 5 5 5 | 47.7 45.7 52.0 49.9 | 31.5 33 29 30 | ||||
SMCG5647 SMCG5647A sMCG5648 SMCG5648A | SMCJ5647 SMCU5647A MCJ5648 SMCJ5648A | 35.1 37.1 38.7 40.9 | 42.9 41.0 47.3 45.2 | 1 1 1 1 | 31.6 33.3 34.8 36.8 | 5 5 5 5 | 56.4 53.9 61.9 59.3 | 26.5 28 24 25.3 | ||||
SMCG5649 SMCG5649A SMCG5650 SMCG5650A | SMCJ5649 SMCJ5649A BMCJ5650 SMCJ5650A | 42.3 44.7 45.9 48.5 | 51.7 49.4 56.1 53.6 | 1 1 1 1 | 38.1 40.2 41.3 43.6 | 5 5 5 5 | 67.8 64.8 73.5 70.1 | 22.2 23.2 20.4 21.4 | ||||
SMCG5651 ChcG56514 SMCG5652 SMCG5652A | SMCJ5651 SMCJ5651A SMCJ5652 SMCJ5652A | 50.4 53.2 55.8 58.9 | 61.6 58.8 68.2 65.1 | 1 1 1 1 | 45.4 47.8 50.2 53.0 | 5 5 5 5 | 80.5 77.0 39.0 85.0 | 18.6 19.5 16.9 17.7 | ||||
SMCG5653 SMCG5653A SMCG5654 SMCG5654A | SMCJ5653 SMCJ5653A SMCJ5654 SMCJ5654A | 61.2 64.6 67.5 71.3 | 74.8 /1.4 82.5 78.8 | 1 1 1 1 | 55.1 58.1 60.7 64.1 | 5 5 5 5 | 98.0 92.0 108 103 | 15.3 16.3 13.9 14.6 | ||||
SMCG5655 SMCG5655A SMCG5656 SMCG5656A | SMCJ5655 BMCJ5655A SMCJ5656 SMCJ5656A | 73.8 77.9 81.9 86.5 | 90.2 86.1 100.0 95.5 | 1 1 1 1 | 66.4 70.1 73.7 77.8 | 5 5 5 5 | 118 113 131 125 | 12.7 13.3 11.4 12.0 | ||||
SMCG5657 SMCG5657A SMCG5658 SMCG5 658A | sMCJ5657 SMCJ5657A SMCJ5658 SMCJ5658A | 90 95 99 105 | 110 105 121 116 | 1 1 1 1 | 81.0 85.5 89.2 94.0 | 5 5 5 5 | 144 137 158 152 | 10.4 11.0 9.5 9.9 | ||||
SMCG5659 SMCG5659A SMCG5660 SMCG5660A | SMCJ5659 SMCJ5659A SMCJ5660 SMCJ5660A | 108 114 124 | 132 126 143 137 | 1 1 1 1 | 97.2 105 111 | 5 5 5 5 | 173 187 179 | 8.7 9.1 8.0 8.4 | ||||
SMCG5661 SMCG5661A SMCG5662 SMCG5662A | SMCJ5661 SMCJ5661A BMCJ5662 SMCJ566 2A | 135 143 152 | 165 158 176 168 | 1 1 1 1 | 121 128 130 136 | 5 5 5 5 | 215 207 230 219 | 7.0 7.2 6.5 6.8 | ||||
SMCG5663 SMCG5663A SMCG5664 SMCG5664A | BMCJ5663 SMCJ5663A sMCJ5664 SMCJ5664A | 53 162 71 | 187 179 198 189 | 1 1 1 1 | 138 145 146 154 | 5 5 5 5 | 244 234 258 246 | 6.2 6.4 5.8 6.1 | ||||
SMCG5665 SMCG5665A | CJ566 SMCJ5665A | 180 190 | 220 210 | 1 1 | 62 171 | 5 5 | 287 274 | 5.2 5.5 |
Microsemi 是美國高可靠性電子元器件廠商,其軍級二三級管產品,被廣泛應用于全球高端市場,深圳市立維創展科技有限公司,授權代理銷售Microsemi軍級二三級產品,大量原裝現貨,歡迎咨詢。
