DATEL模數轉換器（傳統）
發布時間：2021-04-22 17:09:40 瀏覽：847
模數轉換器(A/D轉換器)，簡稱ADC，通常情況下是一種將模擬信號轉換成數字信號的電子元器件。由于數字信號本質上沒有實際意義，它只表述一個相對性大小。為此，任何的模擬數字轉換器都需要一個參照模擬用作轉換標準規定，更普遍的參照標準規定是最大可轉換信號大小。輸出數字量表述輸入信號相對性于參照信號的大小。
模數轉換器最重要的技術參數是轉換精度，它通常情況下用輸出數字信號的位數來表述。轉換器能精準輸出的數字信號越多，轉換器識別輸入信號的工作能力就越強，變換器的性能指標就越好。
A/D轉換通常情況下經過采樣、保持、量化和編碼四個過程。在實際情況電路中，采樣和保持、量化和編碼是在轉換過程中同時實現的。
DATEL模數轉換器(傳統式)特征
傳統的12位分辨率并行和串行輸出的SARA/D轉換器
表面貼裝版
選用MIL-STD-883濾波的高可靠性模型.
深圳市立維創展科技有限公司，優勢提供DATEL產品渠道，歡迎咨詢。
詳情了解DATEL請點擊：/brand/66.html
或聯系我們的銷售工程師：0755- 83642657 QQ： 2295048674
 Part Number
| Resolution | Sampling Rate | Power Consumption | Operating Temp. Range (min) | Operating Temp. Range (max) | RoHS |
|
|
|
|
|
|
|
5962-8850801XC | 12 Bit | N/A | N/A | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
5962-8850802XA | 12 Bit | N/A | N/A | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
5962-8850802XC | 12 Bit | N/A | N/A | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-85/883 | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-85MC | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-85MC-C | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-85ME | 12 Bit | 0.125 MHz | 1.1 W | -40 oC | +100 oC | No |
|
|
|
|
|
|
|
ADC-85ME-C | 12 Bit | 0.125 MHz | 1.1 W | -40 oC | +100 oC | Yes |
|
|
|
|
|
|
|
ADC-85MM | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-85MM-C | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HS12BMC | 12 Bit | 0.1 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-HS12BMC-C | 12 Bit | 0.1 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-HS12BME | 12 Bit | N/A | N/A | -40 oC | +100 oC | No |
|
| |
|
|
|
|
ADC-HS12BME-C | 12 Bit | N/A | N/A | -40 oC | +100 oC | Yes |
|
|
|
|
|
|
|
ADC-HS12BMM | 12 Bit | 0.1 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HS12BMM-C | 12 Bit | 0.1 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HS12BMM-QL | 12 Bit | 0.1 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HS12BMM-QL-C | 12 Bit | 0.1 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HX/883 | 12 Bit | 0.05 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HX12BGC | 12 Bit | 0.05 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-HX12BMC | 12 Bit | 0.05 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-HX12BMC-C | 12 Bit | 0.05 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-HX12BMM | 12 Bit | 0.05 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HX12BMM-C | 12 Bit | 0.05 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HX12BMM-QL | 12 Bit | 0.05 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HX12BMM-QL-C | 12 Bit | 0.05 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HX12GBC-C | 12 Bit | 0.05 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-HZ/883 | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HZ12BGC | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-HZ12BGC-C | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-HZ12BMC | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | No |
|
|
|
|
|
|
|
ADC-HZ12BMC-C | 12 Bit | 0.125 MHz | 1.1 W | 0 oC | +70 oC | Yes |
|
|
|
|
|
|
|
ADC-HZ12BMM | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HZ12BMM-C | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | Yes |
|
|
|
|
|
|
|
ADC-HZ12BMM-QL | 12 Bit | 0.125 MHz | 1.1 W | -55 oC | +125 oC | No |
|
|
|
|
|
|
|
ADC-HZ12BMM-QL-C | 12 Bit | 0.125 MHz | 1.687 W | -55 oC | +125 oC | Yes |
