Q-Tech太空晶體振蕩器

發布時間：2020-12-31 15:43:41 瀏覽：1373

Q-Tech是太空晶體振蕩器的世界領先生產商，所有的這些振蕩器都能承擔至少100kRad(Si)TID電磁輻射。

Q-Tech的全空間設計提供了300kRad(Si)TID的最高電磁輻射容限。

Q-Tech公司推行了一種多輸出LVDS晶體振蕩器(QT625LW/QT697LW)，Q-Tech在一個單一混合扁平封裝中有2到12個差動輸出對。

相對于低地球軌道(LEO)應用領域，Q-Tech公司推行了QT780系列、QT723和QT735振蕩器，它們提供了最低50kRad(Si)TID電磁輻射容限。

深圳市立維創展科技有限公司授權代理銷售Q-TECH產品，備用部分現貨，歡迎與業界同行合作。

詳情了解Q-Tech請點擊：/brand/60.html

或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674

包	市場	設備類型	邏輯類型	電源電壓	穩定性	相位本底噪聲
B+ QT101, QT106, QT141, QT142, QT122, QT128, QT125, QT127, QT126, QT129, QT130, QT178, QT188, QT189, QT190, QT192, QT193, QT194, QT180, QT181, QT182, QT183, QT184, QT185, QT186, QT187	Space	XO	ACMOS, HCMOS, LVCMOS, TTL, LVDS, LVPECL	2.5 to 5.0Vdc	±25ppm to ±100ppm	Contact Q-Tech
QT180, QT181, QT182, QT183, QT184, QT185, QT186, QT187, QS180, QS181, QS182, QS183, QS184, QS185, QS186, QS187	Space	5x7 w/ 4pt Mount	ACMOS, HCMOS, LVCMOS, TTL, LVDS, LVPECL	2.5 to 5.0Vdc	±25ppm to ±100ppm	Contact Q-Tech
QT2020	Space	MCXO	CMOS, SINE	3.3Vdc	±5ppb to ±30ppb	-176 dBc/Hz @ 10MHz
QT606C	Space	XO	CMOS	4.5 to 5.5Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT606L	Space	XO	CMOS	3.3Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT625C	Space	XO	CMOS	4.5 to 5.5Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT625L	Space	XO	CMOS	3.3Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT625NC	Space	XO	CMOS	5.0Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT625LW, QS625LW	Space	XO	LVDS - 1 to 4 Differential Outputs	3.3Vdc	±50ppm to ±100ppm	Contact Q-Tech
QT627LW, QS627LW	Space	XO	LVDS - 1 to 4 Differential Outputs	3.3Vdc	±50ppm to ±100ppm	Contact Q-Tech
QT625xL, QS625xL, QT625xN, QS625xN	Space	XO	CMOS - 1 to 4 Outputs	3.3Vdc, 2.5Vdc	±50ppm to ±100ppm	Contact Q-Tech
QT627xL, QS627xL, QT627xN, QS627xN	Space	XO	CMOS - 1 to 4 Outputs	3.3Vdc, 2.5Vdc	±50ppm to ±100ppm	Contact Q-Tech
QT625S	Space	SAW	SINE	3.3 or 5.0V	±50ppm to ±100ppm	-170 dBc/Hz @ 500MHz
QT641C	Space	XO	CMOS	4.5 to 5.5Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT641L	Space	XO	CMOS	3.3Vdc	±5ppm to ±65ppm	Contact Q-Tech
QT697LW, QS697LW	Space	XO	LVDS - 6, 8, or 12 Differential Output	3.3Vdc	±50ppm to ±65ppm	Contact Q-Tech
QT778, QT780, QT781, QT782, QT783, QT784, QT785, QT786, QT787, QT788, QT789, QT790, QT792, QT793, QT794, QS778, QS780, QS781, QS782, QS783, QS784, QS785, QS786, QS787, QS788, QS789, QS790, QS792, QS793, QS794	Space	XO	CMOS	1.8 to 5Vdc	±25ppm to ±100ppm	-162 dBc/Hz @ 40MHz
QT723, QS723	New Space	XO	CMOS	1.8 to 3.3Vdc	±50ppm to ±100ppm	Contact Q-Tech
QT735, QS735	New Space	XO	CMOS, LVDS, LVPECL	1.8 to 5Vdc	±25ppm to ±100ppm	Contact Q-Tech
QT10T	QPL	M55310/08J	TTL	5Vdc
